One-setup 5-axis work
Simultaneous 5-axis motion reaches undercuts and screw channels without re-fixturing.
SDM5T
SDM5T 5-Axis Dental Milling Machine
5-axis CAD/CAM milling for in-house dental production
The SDM5T is a CAMDENT 5-axis dental milling machine for zirconia, PMMA, wax and PEEK restorations. It brings crowns, bridges, implant bars and full-arch work in-house with an open STL workflow and 24/7 remote support.
Specifications
| Axes | 5-axis simultaneous |
|---|---|
| Cutting type | Wet & dry dual-use |
| Spindle power | 3 kW |
| Spindle speed | 60,000 rpm |
| Spindle cooling | Water-cooled |
| Tool magazine | 30 positions |
| Positioning accuracy | ±0.005 mm |
| Rotation angle | A ±360°, B ±30° |
| Dimensions (L×W×H) | 800 × 1000 × 1600 mm |
| Net weight | 435 kg |
| Processable materials | Titanium, Zirconia, PMMA, PEEK, Wax, Glass ceramic |
Gallery
Applications
- Crowns & bridges
- Implant bars & bridges
- Veneers & inlays
- Full-arch restorations
What's in the box
- SDM5T milling unit
- Starter tool set
- Blank holder & fixtures
- Toolbox & calibration gauge
- Software & manuals
Materials
- Zirconia
- PMMA
- Wax
- PEEK
- Composite resin
Key advantages
Open software workflow
Import open STL from any scanner or CAD — no locked ecosystem.
Remote diagnostics
Built-in remote-assist for calibration, updates and training.
Documented after-sales
Installation and maintenance recorded step by step on our YouTube channel.
Frequently Asked Questions
Zirconia, PMMA, wax, PEEK and composite resin in dry mode; a wet kit covers glass ceramic and CoCr.
Yes — any scanner or CAD that exports open STL/PLY works, with profiles for hyperDENT and MillBox.
Remote installation, live commissioning and unlimited access to the CAMDENT tutorial library.
